AutoCAD Electrical Course Schedule

Course Duration - 40 Hours

Total Number of Classes: 20

Duration Per Class - 02 Hours

Class Schedule Detail:-

 Day-1 (02 Hours)

Topics:

1 Welcome Screen

2 Drawing opening

3 Introduction - Application Manu, Quick Access Tool Bar, Titel Bar, Ribbon Tab, View Cube, Navigation Bar, Command Bar, Status Bar

4 Gridmode (F7)

5 Draw a Line (L)

6 Draw a PolyLine (PL)

7 Orthomode (F8)

8 Polar tracking (F10)

9 Snapmode (F9)

10 Objects Snap

11 Arc (A)

12 Circle (C)

13 Ellipse (EL)

14 Change Object Properties: Type,Collor,Weight

15 Match Propertise

16 Use Of Muse and Keyboard

17 File Save (Ctrl+S)

Day-2 (02 Hours)

Topics:

1 Object Selection (SEL)

2 Angle & Rotate (RO)

3 Rectangle (RE)

4 Polygon (POL)

5 Unit Setup (UN)

6 Dimension Style (D)

7 Dynamic Input

8 Move (M)

9 Copy (CO)

10 Offset (0)

11 Trim (TR)

13 Extend (EX)

14 Join (j)

15 Explode (X)

16 Break At Point

17 Mirror (MI)

18 Understanding co-ordinate system

Day-3 (02 Hours)

Topics:

1 Cursor Size (OP)

2 Pan (P)

3 Text (T)

4 Find & Replace (FIN)

5 Point (PO)

6 Multiple Point

7 Divide (DIV)

8 Measure (ME)

9 Stretch (S)

10 Fillet (F)

11 Chamfer (CHA)

12 Rectangular Array (AR)

13 Polar Array (AR)

14 Path Array (AR)

15 Regen (RE)

Day-4 (02 Hours)

Topics:

1 Hatch (H)

2 Wipeout

3 Select Similar

4 Check Object Proparties

5 Quick Selection (QSE)

6 Groups & Measure

7 Clipboard

8 Scale (SC)

9 Spline (SPL)

10 Xline (XL)

11 Ray

13 Donut (DO)

14 Block (B)

15 Layer (LA)

16 Software Reset

17 How to create basic dimensions

18 Limits

Day-5 (02 Hours)

Topics:

Working with project in AutoCAD Electrical:-

(1) Project manager interface of AutoCAD Electrical

(2) Learn project workflow in AutoCAD Electrical

(3) Introduction & accessing with project files in AutoCAD Electrical

(4) Opening and closing project

(5) Create a project & set project properties.

(6) How to copy a project

(7) How to delete a project

(8) Understanding standards and templates

(9) How to activate a project

(10) Wdm block, surfer tool & existing project layers

(11)Project-wide update/retag

Day-6 (02 Hours)

Topics:

Working with drawing in AutoCAD Electrical:-

(1) Create a drawing & set drawing properties

(2) How to open a drawing

(3) How to configure the drawing list display

(4) Removing a drawing from a project

(5) Grouping drawing within a project

(6) Add & managing a drawing to a project

(7) Comparing/matching drawing and project setting

(8) Create a project & create a drawing in this project

(9) Add a drawing from demo project

(10) Add subfolder

Day-7 (02 Hours)

Topics:

Working with wiring in AutoCAD Electrical:-

(1) Inserting wires & inserting wires at angles

(2) How to insert & extend multiple bus wiring

(3) How to trimming a wires

(4) How to create, change & set default wire types

(5) How to insert single & three phase type wire numbers

(6) How to copy, move & delete a wire number

(7) How to edit, hide & unhide a wire number

(8) How to swap, flip & scoot a wire numbers

(9) How to finding & replacing with toggling wire numbers

(10) Wire numbers with leaders

Day-8 (02 Hours)

Topics:

Working with wiring in AutoCAD Electrical:-

(11) Wire identification using cable markers

(12) How to set wire color and gauge labels

(13) How to stretching & bending wires at right angles

(14) How to checking, tracing a wire and line entities

(15) Insert, check, flip, delete wire gaps & loops

(16) How to add source & destination signal arrows

(17) How to edit source and destination signal arrows

Day-9 (02 Hours)

Topics:

Working with ladder & rungs in AutoCAD Electrical:-

(1) How to insert a single & three phase ladder

(2) How to renumber ladder rung references

(3) How to resize & re-positioning a ladder

(4) How to add rungs & remove ladder rungs with rung spacing

(5) How to convert objects to a ladder

(6) How to insert x-y grid labels

(7) How to insert x zone labels

Day-10 (02 Hours)

Topics:

Working with schematic components in AutoCAD Electrical:-

(1) Introduction with schematic components (iec, ieee)

(2) How to insert single & three phase components

(3) How to insert & edit parent & child components

(4) Working with existing part number

(5) Working with project specific catalog database

(6) Inserting components from the equipment list

(7) Inserting components from the catalog browser

(8) Edit & add a catalog entry

(9) Inserting components from panel lists

(10)Swapping and updating blocks

Day-11 (02 Hours)

Topics:

Using PLC symbols in AutoCAD Electrical:-

(1) Inserting parametric PLC modules

(2) Inserting & modifying full unit PLC modules

(3) Working with individual PLC to points & database editor

(4) Using the spreadsheet to PLC i/o utility (export & import)

Day-12 (02 Hours)

Topics:

AutoCAD Electrical editing commands:-

(1) Using copy, move & scoot in components

(2) Using align, toggle, delete & dashed link lines

(3) Using the surfer command

(4) Using attribute edit tools

Hands-on:

(1) Star delta ladder diagram

Day-13 (02 Hours)

Topics:

Working with terminals in AutoCAD Electrical:-

(1) Inserting terminals from icon menu

(2) Inserting terminals from schematic list & manually

(3) Terminal block associations properties & terminal strips

(4) Using jumpers in terminal block

(5) Generating terminal tables

Day-14 (02 Hours)

Topics:

Working with connector diagram in AutoCAD Electrical:-

(1) Inserting connectors

(2) Adding, deleting, moving & swapping connector pins

(3) Reversing, rotating & stretching a connector

(4) Spliting a connector & editing pin numbers

(5) Using point-to-point wiring diagrams & splices

Hands-on:

(1) Forward reverse controlling diagram

(2) Forward reverse power diagram

Day-15 (02 Hours)

Topics:

Creating symbols in AutoCAD Electrical:-

(1) Creating custom symbols

(2) Editing custom symbols

(3) Add to icon menu & inserting from icon menu

Hands-on:

(1) Star delta controlling diagram

(2) Star delta power diagram

Day-16 (02 Hours)

Topics:

Working with schematic circuits in AutoCAD Electrical:-

(1) Working with wblock

(2) Working with circuits (icon menu)

(3) Move & copy circuits

(4) Working with circuit clipboard

(5) Working with circuit builder

Day-17 (02 Hours)

Topics:

Working with panel layout drawing in AutoCAD Electrical:-

(1) Inserting from icon menu & edit footprint

(2) Another way inserting & coping footprint

(3) Inserting balloons & rename panel layers

(4) Re-sequencing & nameplates

(5) Working with panel drawing configuration & din rail

Day-18 (02 Hours)

Topics:

Generating reports in AutoCAD Electrical:-

(1) Creating reports

(2) Report format setup

(3) Run automatic reports

(4) Using the electrical audit command

Day-19 (02 Hours)

Topics:

Application of Blocks and Attributes:-

(1) How to create & insert simple blocks

(2) Modifying, redefining, writing & global block

(3) How to make and modify attributes

(4) How to create and insert attributed blocks

(5) AutoCAD Electrical title blocks

Day-20 (02 Hours)

Topics:

Hands-on:

Create a panel layout for Distribution Board with Residual Current Device (RCD) – Single phase.
